Article description:

ESP32 WiFi 16CH module

Already flashed with the latest Tasmota firmware.

It is a 16-bit relay driver module that can realize mobile phones, computers and remote controls.

Supports a programming mode to install your own programs.

Article description:

16 channel relay DC 5V / 12V / 24V

It is a 16-channel relay interface card that can be directly controlled by a wide range of microcontrollers such as Arduino (8051, AVR, PIC, PLC, DSP, ARM, MSP430, TTL logic).

The relay is able to control various devices and other equipment with high energy requirements.

Uses two 8-channel ULN2803APG Darlington array chips to control the relay module.

The maximum switching value of the relay output is AC250V 10A and DC30V 10A.

Optocoupler with industrial insulation. Strong anti-interference ability. The trigger current is only 3mA.

The operating status indicator lights are for safe use.

Widely used for all MCU controls, industrial areas, PLC controls, smart home controls.

4 mounting holes for easy installation.


Notes:

Relays 6,7,10 and 14 are always switched ON and OFF when the board is powered, causing a brief on/off pulse on the relay as Tasmota charges it and turns it off again. If the last state was ON, then of course it remains ON.

All 16 channels could be controlled via the following interfaces: Serial, WebGUI, MQTT, HTTP. Alexa or app control via the outdated FriendlyNames, however, is only limited to the first 8 channels.


Technical data ESP32 module:

Model: ESP 32 16-bit relay driver module

Input voltage: DC 5V

ChipSet: ESP32 main control chip

Working temperature: -25 to 80°C

Working humidity: 5% - 95%

Size: 45.5 x 40.5 x 12.5 mm

Technical data relay:

Model: DC5V - DC12V - DC24V 16-fold relay

Input voltage depending on model: DC 5V / DC 12V / DC 24V

Size: 176mm x 90mm x 17mm

Weight: 240g

The board contains 10A/250V AC 10A/30V DC relay

Standard interface for control modules (16 IE port, DC5V Out Plus, DC5V Out Ground)


100% tested new goods available immediately with Tasmota firmware

Type variants:

5V relay without ESP32 module 24V relay without ESP32 module ESP32 module without relay 5V relay incl. ESP32 module 12 v Relay incl. ESP32 module 24V relay incl. ESP32 module

Model variants:

Tasmota german Original (no firmware)
