NOUS B4Z Zigbee 3.0 Smart Curtain Module Curtain Roller Shutter Switch AC - DC

Article description:

Zigbee 3.0 Smart roller shutter switch

Technical data:

KEY FEATURES

Brand: Nous

Special features: Works with an app or locally in Home Assistant with zigbee2mqtt or zha, without a power meter.

Compatibility: Requires Zigbee 3.0 Hub/Gateway

Material: PC V0 flame-retardant plastic housing

SPECIFICATIONS

Device dimensions: 42*37*16mm

Maximum load: 10A/channel, 16A total, DC: 10A

Operating temperature: 0ºC ~ 40 ºC

Operating voltage range: 100-240VAC / 24-30VDC

Moisture protection class: IP20

Device weight: 30g

NETWORK

Communication standard: IEEE 802.15.4

Protocol: Zigbee 3.0

Control via smartphone: Nous smart, Tuya smart life app, Home Assistant, etc.

Compatibility with voice assistants: Alexa, Google Assistant

Frequency range: 2400 - 2483 MHz

Max. Transmission power: 10 dBm

OTHER

Warranty: 24 months

Scope of delivery: module, instructions

Manufacturer: L-TRADE Sp z o.o.
