SONOFF MINI-ZBDIM Mini Extreme Zigbee Dimmer Switch Power Monitoring 400W Max

Product Description:

The SONOFF MINI-ZBDIM is an ultra-compact Zigbee 3.0 dimmer that allows existing lighting circuits to be easily and cleanly transformed into smart solutions. It offers smooth, flicker-free dimming with precise percentage control and gentle transitions.

The module is designed in the Mini Extreme format and fits comfortably behind standard wall switches. It supports both momentary (push-button) and toggle switches, which can be selected directly on the device.

Thanks to the Zigbee-based control, the MINI-ZBDIM integrates into brand-independent smart homes and is compatible with Home Assistant (ZHA / Zigbee2MQTT), SONOFF gateways (e.g., NSPanel Pro, iHost), and other Zigbee 3.0 hubs.

Additional Features:

Protocol: Zigbee 3.0

Compatibility: Home Assistant (ZHA, Zigbee2MQTT), SONOFF Zigbee gateways (NSPanel Pro, iHost), and other Zigbee 3.0 hubs.

Voice Control: Works with Alexa, Google Home, SmartThings (via Zigbee hub integration).

Local Control: Operation with wall switch possible even without internet connection.

Remote control and dimming: Status control, scenes, and automations are supported via Zigbee.

Calibration and Minimum Brightness: Helps to avoid flickering and set the usable dimming range.

Transition Times: Configure smooth brightness transitions.

Grouping: Synchronize multiple lighting circuits for unified control.

Technical Specifications:

Model: MINI-ZBDIM

Dimensions: 45 × 39.4 × 16.8 mm

Weight: 35 g

Operating Temperature: −10…+40 °C

Operating Humidity: 5–95% RH, non-condensing

Material: PC plastic

Protocol: Zigbee 3.0

Rated Load: Max 400 W (resistive load); LED: 200 VA

Recommended Wiring: 18–16 AWG solid/stranded copper (SOL/STR)

Product Category: dimmer

Conductor Cross-section: 1, 5 mm2

Rated Power (Output): 400W

Color: White

Net Weight: 24.5 g

Device power supply: 230V AC (L + N)

Output circuits / gangs: 1

Operating temperature range: -10°C - 40°C

Operating humidity range: 5% - 95% RH

IP rating: IP20

Size: 39.4 x 45 x 16.8 mm

Colour: white
