SONOFF MINI-ZBRBS-E Orb-ZBRBS Zigbee Smart Roller Shutter Wall Switch white

Product Description:

The SONOFF MINI-ZBRBS-E Orb-ZBRBS is a Zigbee-enabled wall switch for roller shutters that transforms conventional electric blinds, curtains, or motorized shades into remotely controllable devices. It connects via the Zigbee 3.0 protocol to a compatible Zigbee hub, allowing control through a mobile app, automation routines, or voice assistants.

The Orb-ZBRBS enables precise position control in percentages (e.g., 25%, 50%, or 80%) and supports daily schedules and scenes. Additionally, it enhances the stability of the Zigbee network through its function as a signal repeater. The modern white design fits most European flush-mounted boxes.

It is important to note that the maximum supported load is 1 ampere, making it unsuitable for larger motors over 30 Nm.

Additional Features:

Zigbee 3.0 protocol: Reliable and fast wireless communication.

Precise position control: Setting the positions of blinds or curtains to any percentage.

Schedules and scenes: Automation of opening/closing based on daily routines or times of day.

Voice control: Compatible with Alexa and Google Home (depending on the hub/platform).

Zigbee router function: Strengthens and stabilizes your Zigbee network.

Manual control: Physical buttons allow local control without network or internet access.

Technical Specifications:

Application area: Suitable for standard roller shutters or motorized blinds

Model: MINI-ZBRBS-E

MCU: Silicon Labs EFR32MG21

Maximum load: 1 A (for shutter motor)

Dimensions: 86 × 86 × 34 mm

Color: White

Recommended wiring: 18 AWG – 14 AWG, solid or stranded copper

Operating temperature: -10 ℃ to +40 ℃

Operating humidity: 5–95% RH, non-condensing

Product category: roller shutter control

Conductor cross-section: 1, 63 mm2

Rated voltage (output): 230V AC

Rated power (output): 240W

Weight: 125 g/pcs

Net weight: 84.1 g

Housing material: PC (polycarbonate)

Device power supply: 230V AC (L + N)

Output circuits / gangs: 2

Operating temperature range: -10°C - 40°C

Operating humidity range: 0% - 95% RH

IP rating: IP20

Size: 86 x 86 x 34 mm

Colour: white
