SONOFF NSPanel Touch Display Wall Switch Smart Scene Wall Switch Tasmota

Article description:

WiFi Smart Scene Touch Display Wall switch

Already flashed with the latest Tasmota firmware.

The Sonoff NS Panel is a smart home switch with 8.89cm / 3.5 inch display. Two separate channels can be switched via the two buttons (lamp 1 & lamp 2). The display can be operated easily and quickly. Due to the integrated temperature knife, the current temperature is displayed in the display. There is also the possibility to display widgets on the NS panel. The NS panel can be assembled in any commercially available flush -mounted box.

All in One Control Center - you can control and regulate different scenes via the Sonoff NS Panel. The NS panel is compatible with almost all sonoff devices.

Home Automation Thermostat - With the built -in powerful thermostat, different interior temperatures can be set at different times and the NS panel is automatically activated the heating or cooling devices according to your settings in order to keep the room to a temperature determined by you.

Knowing time & weather - Due to the built -in sensors and the WiFi connection, the NSPANEL can show you the weather, the inside and outside temperatures as well as time and date.

to match:

Splash -proof housing

The waterproof box R2 from Sonoff consists of PC V0 material, which is dustproof and prevents objects from entering. Which makes it ideal for protecting your sonoff switch in moist environments.

SONOFF Waterproof Box R2 IP64 TH-Elite TH-Origin POW-Elite POW-Origin NSPanel TX

Special features of the Tasmota firmware

Up to 8 widgets in 12 different designs can be represented on the NSPANEL.

Both relays as well as buttons, summer and temperature sensor belong to Tasmota like any standard switch.

Use the "Buzzer" command to control the Summer.

To set the widgets and thermostat settings to be used, you have to edit the variables "Widget" and "ATC" in the NSPANEL.BE file.

The condition of the relay is displayed with "Set_power ()" in the driver on the lower bar of the main screen.

Time and date are automatically updated every minute according to the Tasmota time with "Set_Clock ()".

Weather updates are used with NSPLOCATION VALUE "Set_weather ()" function to get data from WTTR.In. Since no date area can currently be made available, it was replaced by the use of the perceived temperature.

The internal temperature is updated in telepaniod using "Set_Temp ()" functions using the data of the NSPANEL temperature probe. You can change the source by arriving the associated "tasota.add_rule" trigger, or updating with remote access with npsend {"temperature": 24.5, "tempunit": "c"}.

Every contact event is reported in the Tasmota protocols and can be used in Rules with the trigger "NSpanel#...".

If you want to have the opportunity to reset the screen, change GPIO4 in "Relay 3". This PIN must be low so that the screen switches on, so put the pulsetime3 2 to temporarily pull it up so that the screen can be reset.

Important NOTE:

The NSPANEL as a Tasmota variant is already delivered with the preset template. All other settings still have to be configured to your individual wishes. Json commands are used for this. There should be a certain basic knowledge so that you can realize it yourself.

You can find more information about the facility on: https://templates.blakadder.com/sonoff_nSpanel.html

NS Panel Lovelace UI

The NSPANEL can easily be switched from the Tasmota console to the popular Lovelace UI.

NSPANEL LOVELACE UI is a firmware for the NEXION screen within NSPANEL in the design of HomeSistant's Lovelace UI Design.

At https://docs.nspanel.pky.eu/ you will find installation instructions and documentation of the configuration.

Everything is dynamically configurable by a Yaml configuration, no need to program or use NEXION EDITION

It works with Tasmota and MQTT. There is an Appdaemon app for controlling the panel and updating with content of home assistant.

Technical data:

Model: NSPANEL-EU

Wi-Fi type: IEEE 802.11 B/g/n 2.4GHz

Security protocol: WEP/WPA-PSK/WPA2-PSK

Bluetooth: 4.2 BLE

Size: 86 x 86 x 41.7 mm

Display size: 8.89cm / 3.5 inches

Display resolution: 480x320px

Input voltage: 100V ~ 240V AC (50/60Hz)

Max. Input current: 4A (2a per channel)

Max. Power: 600W (300W per channel)

Material: PC V0 + CRS + hardened glass
